Honda BF135 (135HP)

Please Contact Us For Pricing

Honda’s BF135 delivers seamless performance and optimum power for a smooth and enjoyable boating experience. Based on the same reliable engine that powers the globally-popular Honda Accord, it has been manufactured with the world’s most innovative, efficient and reliable technology.

The BF135 offers power-to-weight ratios to rival two-stroke engines in the same class. Designed for use in all environments, this engine features a unique set of Honda-exclusive technologies to provide increased power across the entire rev range.

Low fuel consumption, exceptional reliability and reduced periodical maintenance requirements all combine to minimise the overall cost of ownership.

SPECIFICATIONS
TYPE 4-stroke DOHC inline 4-cylinder / 16-valves
DISPLACEMENT 2,354cc
BORE & STROKE 87 x 99 mm
FULL THROTTLE RPM RANGE 4,500-6,000 RPM
RATED POWER 115HP @ 5,250 RPM
COOLING SYSTEM Water cooled
INDUCTION Programmed fuel injection
IGNITION SYSTEM Full transistorised battery ignition
STARTING SYSTEM Electric
EXHAUST Through prop
ALTERNATOR 40-Amp
POWER TRIM & TILT Standard
TRIM RANGE -4° to +16°
TILT RANGE 68°

SAFETY FEATURES
EMERGENCY STOP SWITCH Standard
OIL PRESSURE ALERT Standard
TEMPERATURE ALERT Standard
REV-LIMITER Standard
SPEEDOMETER PICKUP Standard

DRIVE
GEAR RATIO 2.14:1
GEAR SHIFT F-N-R
PROPELLER Optional

DIMENSIONS
OVERALL LENGTH 845mm
OVERALL WIDTH 580mm
OVERALL HEIGHT (L-TYPE) 1,665mm
OVERALL HEIGHT (X-TYPE) 1,790mm
OVERALL HEIGHT (XXL-TYPE) n/a
TRANSOM HEIGHT (L-TYPE) 508mm
TRANSOM HEIGHT (X-TYPE) 635mm
TRANSOM HEIGHT (XXL-TYPE) n/a
DRY WEIGHTS (L-TYPE) 217kg
DRY WEIGHTS (X-TYPE) 220kg
